FAST Series
Commercial all-in-one Level 3 charging in 60 kW, 120 kW and 180 kW configurations. FAST Series combines dual CCS1/NACS charging, integrated payment, ICAPIA CSMS management, a 10.1-inch user touchscreen and a remotely managed 21.5-inch advertising display.
Single / Dual-Port Power
Charging Ports
Output Range
Advertising Display
Single / Dual-Port Power
Charging Ports
Output Range
Advertising Display
Single / Dual-Port Power
Charging Ports
Output Range
Advertising Display
Description
Commercial DC Fast Charging for High-Utilization Sites
The ICAPIA FAST Series is an all-in-one Level 3 charging platform available in the three core power configurations most commercial sites need: 60 kW, 120 kW and 180 kW. Dual charging outlets, CCS1 and NACS connector options and a wide 150–1000 VDC output range support a broad mix of electric vehicles.
Choose Your Power Level
| Model | Maximum Output | Charging Outlets | Typical Use |
|---|---|---|---|
| FAST 60 | 60 kW | Dual | Workplaces, retail and destination charging |
| FAST 120 | 120 kW | Dual | Public charging, fleets and commercial sites |
| FAST 180 | 180 kW | Dual | High-throughput public and fleet charging |
Two Displays, One Better Charging Experience
A 10.1-inch touchscreen guides drivers through charging and payment, while the integrated 21.5-inch advertising display can present promotional or informational content updated remotely from cloud storage. Cable-management options keep the charging area organized and easier to use.
Connected Operations and Payments
The FAST Series connects to the ICAPIA CSMS for load management, pricing schedules, remote monitoring, diagnostics, reporting and over-the-air updates. Wi-Fi, 4G and Ethernet connectivity are supported, together with app, RFID and direct card-payment access.
Built for Commercial Deployment
A Type 3R enclosure, forced-air cooling and comprehensive electrical and environmental protections support demanding outdoor operation. The FAST Series uses 480 VAC three-phase input and supports OCPP 1.6J with an upgrade path to OCPP 2.0.1.
Additional information
| Power Configurations | 60 kW, 120 kW, 180 kW |
|---|---|
| Input Supply | 480 VAC ±10%, three-phase + PE, 50/60 Hz |
| Output Voltage | 150–1000 VDC |
| Charging Outlets | Dual outlet; CCS1 + CCS1, CCS1 + NACS, or NACS + NACS |
| Connectivity | Wi-Fi, 4G, Ethernet |
| Authentication | App, RFID card; POS machine optional |
| Displays | 10.1-inch LCD touchscreen; 21.5-inch advertising display |
| Network Protocol | OCPP 1.6J; upgradable to OCPP 2.0.1 |
| Cable Length | 16.4 ft standard; customizable up to 23 ft |
| Operating Temperature | -13°F to +122°F |
| Enclosure Rating | Type 3R |
| Standards & Certification | UL 2202, UL 2231, FCC Part 15; ETL certified |
